01 PRI Equipment
Number
Enter the ISDN RPTU equipment number:
Enter data as XXYYZZ:
• XX=cabinet 01
• YY=03, 05, or 07
• ZZ=Channel 01 is always used to assign RPTU parameters
or
• XX=cabinet 02~10
• YY=01, 03, or 05
• ZZ=Channel 01 is always used to assign RPTU parameters
Example: If the RPTU is installed in cabinet shelf 5, slot 3, enter 050301.
Cabinet numbers:
• CIX/CTX100: Select 01 for Base and Expansion cabinet.
• CIX200: Select 01 for Base and 02 for Expansion cabinet.
• CIX/CTX670: Select 01 for Base and 02~07 respectively for each
Expansion cabinet.
• CIX1200: Select 01 for Base and 02~12 respectively for each
Expansion cabinet.
Slot numbers:
• CIX/CTX100: Select 01~04 for Base slots and 05~08 for Expansion
slots.
• CIX/CTX100: Virtual Slot for ACTU Relay = Cabinet 02, Slot 05.
• CIX200: Select 01~04 for either cabinet.
• CIX/CTX670: Select 01~08 for Base slots and 01~10 for Expansion
slots.
• CIX1200:Select 01~08 for Base slots and 01~10 for Expansion slots.
02 Channel ID An identifier must be used as part of the addressing to communicate with the PSTN
which channel on which link is used on the given call. This identifier is assigned by
the connected PSTN.
Possible values:1~ 126 (default = 1)
03 D-Ch Provided If a backup ‘D’ Channel is to be used it needs to be enabled.
Possible values:D-channel or No D-channel (default)
