Services
External Devices
9-48 Strata CIX Programming Vol.1 12/09
Door phone numbering for CIX200, CIX670/CIX1200 Basic is as follows:
• DDCB 3 provides door phone numbers 7~9, 8 can be a door phone or
door lock.
Door phone numbering for CIX670/CIX1200 Exp. only is as follows:
• DDCB 4 provides door phones 10~12, 11can be a door phone or door
lock.
• DDCB 5 provides door phones 13~15, 14 can be a door phone or door
lock.
• DDCB 6 provides door phones 16~18, 17 can be a door phone or door
lock.
• DDCB 7 provides door phones 19~21, 20 can be a door phone or door
lock.
• DDCB 8 provides door phones 22~24, 23 can be a door phone or door
lock.
DDCBs are numbered by the system automatically by DDCB Equipment
(Shelf/Slot/Circuit). DDCB1 is assigned to the lowest DDCB Equipment
and DDCB2 to the next lowest, etc.
If DDCB Circuit B is set to door lock, a door phone cannot be set.
01 DDCB Equipment No. Enter the DDCB equipment number to which the door phone should be
assigned.
Enter data as XXYYZZ:
XX = cabinet 01~07
YY = slot 01~10
ZZ = analog trunk circuit 01~08, or ZZ = T1 channel 01~24.
Example: If a line should be assigned to an RCOU in cabinet shelf 5, slot 2,
circuit 3, enter 050203.
Cabinet numbers:
CIX100: Select 01 for Base and Exp cabinet.
CIX200: Select 01 for Base and 02 for Exp cabinet.
CIX670: Select 01 for Base and 02~07 for each Exp cabinet.
CIX1200: Select 01 for Base and 02~12 for each Exp cabinet.
Slot numbers:
CIX100: Select 01~04 for Base slots and 05~08 for Exp slots.
CIX200: Select 01 ~ 04 for either cabinet.
CIX670: Select 01~08 for Base slots and 01~10 for Exp slots.
CIX1200: Select 01~08 for Base slots and 01~10 for Exp slots.
F
IELD DESCRIPTION
To Next Page
