SVAN 979 User Manual
Diffuse Field
Digital filter that compensates the diffuse field effect.
Chapter
4.6
SA279 (90
o
)
Digital filter that compensates the effect of the SA 279
outdoor microphone protection unit in the free field for the
reference acoustic wave incidence angle 90 deg.
Chapter
4.6
SA279 (0
o
)
Digital filter that compensates the effect of the SA 279
outdoor microphone protection unit in the free field for the
reference acoustic wave incidence angle 0 deg.
Chapter
4.6
Windscreen
Digital filter that compensates the effect of the SA 22
windscreen when Free Field or Diffuse Field options are
selected.
Chapter
4.6
Range
Position that enables selecting the linear operating range
for the sinusoidal signal: Low or High. The calibration
factor is always added to the range limits.
The ranges depend on the selected Compensation Filter.
Chapter
4.7
Low
Low linear operating range for the sinusoidal signal.
The calibration factor is always added to the range limits.
The range depends on the selected Compensation Filter.
Chapter
4.7
Appendix C
High
High linear operating range for the sinusoidal signal.
The calibration factor is always added to the range limits.
The range depends on the selected Compensation Filter.
Chapter
4.7
Appendix C
