203
SVAN 979 User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code value description
Rolling Time(1)
QF
nn - nn time in seconds  (1  60)
nn - nn time in minutes multiplied by 60  (60
 3600)
Rolling Time(2)
QG
nn - nn time in seconds  (1  60)
nn - nn time in minutes multiplied by 60  (60
 3600)
Exposure Time
e
EP
nnn - nnn time in minutes  (1  480)
Reference Level Acc
Xa
RA
BO
nn - nn reference level  (1  100) in µm/s
2
Reference Level Vel
Xv
RV
BP
nn - nn reference level  (1  100) in nm/s
Reference Level Dil
Xd
RD
BQ
nn - nn reference level  (1  100) in pm
Table A.4. Profile parameters
Group name
#1
code
#7
code
#S
code
Code value description
Filter type in profile n
in SLM mode
F
-3:n R3 filter for profile n
-2:n R2 filter for profile n
-1:n R1 filter for profile n
1:n Z filter for profile n
2:n A filter for profile n
3:n C filter for profile n
4:n G filter for profile n
5:n B filter for profile n
Filter type in profile 1
in SLM mode
AB0
-3 - R3 filter
-2 - R2 filter
-1 - R1 filter
1 - Z filter
2 - A filter
3 - C filter
4 - G filter
5 - B filter
Filter type in profile 2
in SLM mode
AB1
-3 - R3 filter
-2 - R2 filter
-1 - R1 filter
1 - Z filter
2 - A filter
3 - C filter
4 - G filter
5 - B filter
