Svantek SVAN 979 - Page 204

204
SVAN 979 User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code value description
Filter type in profile 3
in SLM mode
AB2
-3 - R3 filter
-2 - R2 filter
-1 - R1 filter
1 - Z filter
2 - A filter
3 - C filter
4 - G filter
5 - B filter
Detector type in profile n in
SLM mode
C
0:n - IMPULSE detector in profile n
1:n - FAST detector in profile n
2:n - SLOW detector in profile n
Detector type in profile 1 in
SLM mode
AC0
0 - IMPULSE detector
1 - FAST detector
2 - SLOW detector
Detector type in profile 2 in
SLM mode
AC1
0 - IMPULSE detector
1 - FAST detector
2 - SLOW detector
Detector type in profile 3 in
SLM mode
AC2
0 - IMPULSE detector
1 - FAST detector
2 - SLOW detector
Logger type in profile n in
SLM mode
B
x:n - x - sum of the following flags
1 - logger with PEAK values in profile n
2 - logger with MAX values in profile n
4 - logger with MIN values in profile n
8 - logger with RMS values in profile n
Logger type in profile 1 in
SLM mode
AD0
x - x - sum of the following flags
1 - logger with PEAK values
2 - logger with MAX values
4 - logger with MIN values
8 - logger with RMS values
Logger type in profile 2 in
SLM mode
AD1
x - x - sum of the following flags
1 - logger with PEAK values
2 - logger with MAX values
4 - logger with MIN values
8 - logger with RMS values
