SVAN 979 User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code value description
Filter type in profile 2
in VLM mode
AR1
-3 - R3 filter
-2 - R2 filter
-1 - R1 filter
0 - HP filter
1 - HP1 filter
2 - HP3 filter
3 - HP10 filter
4 - Vel1 filter
5 - Vel3 filter
6 - Vel10 filter
7 - VelMF filter
8 - Dil1 filter
9 - Dil3 filter
10 - Dil10 filter
21 - Wh filter
Filter type in profile 3
in VLM mode
AR2
-3 - R3 filter
-2 - R2 filter
-1 - R1 filter
0 - HP filter
1 - HP1 filter
2 - HP3 filter
3 - HP10 filter
4 - Vel1 filter
5 - Vel3 filter
6 - Vel10 filter
7 - VelMF filter
8 - Dil1 filter
9 - Dil3 filter
10 - Dil10 filter
21 - Wh filter
Detector type in profile n in
VLM mode
E
0:n - 100ms detector in profile n
1:n - 125ms detector in profile n
2:n - 200ms detector in profile n
3:n - 500ms detector in profile n
4:n - 1.0s detector in profile n
5:n - 2.0s detector in profile n
6:n - 5.0s detector in profile n
7:n - 10.0s detector in profile n
