SVAN 979 User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code value description
Detector type in profile 1 in
VLM mode
CQ0
0 - 100ms detector
1 - 125ms detector
2 - 200ms detector
3 - 500ms detector
4 - 1.0s detector
5 - 2.0s detector
6 - 5.0s detector
7 - 10.0s detector
Detector type in profile 2 in
VLM mode
CQ1
0 - 100ms detector
1 - 125ms detector
2 - 200ms detector
3 - 500ms detector
4 - 1.0s detector
5 - 2.0s detector
6 - 5.0s detector
7 - 10.0s detector
Detector type in profile 3 in
VLM mode
CQ2
0 - 100ms detector
1 - 125ms detector
2 - 200ms detector
3 - 500ms detector
4 - 1.0s detector
5 - 2.0s detector
6 - 5.0s detector
7 - 10.0s detector
Logger type in profile n in
VLM mode
G
x:n - x - sum of the following flags
1 - logger with PEAK values in profile n
2 - logger with P–P values in profile n
4 - logger with MAX values in profile n
8 - logger with RMS values in profile n
Logger type in profile 1 in
VLM mode
CR0
x - x - sum of the following flags
1 - logger with PEAK values in profile n
2 - logger with P–P values in profile n
4 - logger with MAX values in profile n
8 - logger with RMS values in profile n
Logger type in profile 2 in
VLM mode
CR1
x - x - sum of the following flags
1 - logger with PEAK values in profile n
2 - logger with P–P values in profile n
4 - logger with MAX values in profile n
8 - logger with RMS values in profile n
