SVAN 979 User Manual - Appendixes
Table A.8. Tonality parameters
Group name
#1
code
#7
code
#S
code
Code value description
Max Band
MB
DH
xx - xx tonality maximum band in percentage
 (5  25)
Tone Seek
TS
DI
xx - xx tonality tone seek in dB*10  (10  50)
Regression
RE
DJ
xx - xx tonality regression in percentage
 (50  100)
Tone Band
TB
DK
xx - xx tonality tone band in dB*10  (10 
60)
Table A.9. Measurement trigger parameters
Group name
#1
code
#7
code
#S
code
Code value description
Trigger Mode
m
BS
0 - Off
1 - Slope +
2 - Slope –
3 - Level +
4 - Level –
6 - Gradient +
7 - External
Level in SLM mode
l
BW
xxx - xxx level in dB  (24  136)
Level in VLM mode
n
BX
xxx - xxx level in dB  (60  200)
Gradient in SLM mode
O
BY
xxx - xxx gradient in dB/ms  (1  100)
Gradient in VLM mode
k
BZ
xxx - xxx gradient in dB/ms  (1  100)
Table A.10. Logger trigger parameters
Group name
#1
code
#7
code
#S
code
Code value description
Trigger Mode
XT
CA
0 - Off
3 - Level +
4 - Level –
Level in SLM mode
XL
CE
x - x level in dB  (24  136)
Level in VLM mode
XC
CF
x - x level in dB  (60  200)
Logger Pre-triggering
Number of records taken
into account before the
fulfilment of the triggering
condition
XQ
CI
x - x number of records saved in logger
before the fulfilment of the triggering
condition; x  (0  50)
Logger Post-triggering
Number of records taken
into account after the
fulfilment of the triggering
condition
Xq
CJ
x - x number of records saved in logger after
the fulfilment of the triggering condition;
x  (0  200)
