Table A.11. Wave recording parameters
Group name
#1
code
#7
code
#S
code
Code value description
Wave Recording
XXC
KC
0 - Off
1 - Continuous
2 - On Trigger
Format
XXm
IN
0 - PCM
1 - Extensible
Audio Sampling
XXl
GN
0 - 48 kHz
1 - 24 kHz
2 - 12 kHz
Filter in in SLM mode
NH
0 - HP filter
1 - Z filter
2 - A filter
3 - C filter
5 - B filter
Filter in in VLM mode
NI
0 - HP filter
Wave Name for SD card
KE
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Wave Name for USB disk
KF
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Wave Length Limit
AF
x - x number in minutes with step 10 (0 
480)
Trigger on Marker
XXO
BH
0 - Off
1 - On
Trigger Mode
XXu
EZ
1 - Slope +
2 - Slope –
3 - Level +
4 - Level –
7 - External
10 - Integration Period
Trigger Level in SLM mode
XXv
FD
x - x level in dB  (24  136)
Trigger Level in VLM mode
XXw
FE
x - x level in dB  (60  200)
Trigger Period
MB
0 - Log. Step
5 - 0.5 ms
1000 - 100 ms
10000 - 1 s
Recording Time
XXY
FI
0 - Inf
x - x number of seconds (1..60)
x - 60..3600 with step 60
x - 3600..28800 with step 3600
Pre Trigger
XXz
FJ
0 - Off
1 - On
