238
SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
3
LoggerRes
bit mask of results written to logger in vibration measurement mode:
1 – Peak
2 – P–P
4 – Max
8 – RMS
bit mask of results written to logger in sound measurement mode:
1 – Peak
2 – Max
4 – Min
8 – Leq
16 – LR1
32 – LR2
64 – LXY
…
reserved
Table B.1.15. Real Time Filters parameters
Word
number
Name
Comment
0
0nn21h
21h = block identifier
0nnh = block length in words
1
Type[1]
type of the first filter:
0 – highpass filter
1 – lowpass filter
2 – bandpass filter
2
Order[1]
order of the first filter
3..4
LowPole[1]
low pole of the first filter in 10mHz format (parameter not relevant to
low-pass filter)
5..6
HighPole[1]
high pole of the first filter in 10 mHz format (parameter not relevant
to the upper-pass filter)
...
second filter parameters
...
third filter parameters
…
reserved
Table B.1.16. Marker parameters
Word
number
Name
Comment
0
0043h
43h = block identifier
1
BlockLength
block length in words
2
MarkerCount
number of markers
3..7
MarkerName[1]
name of the first marker (10 ASCII symbols)
8
reserved
9
MarkerType[1]
type of the first marker:
0 – block marker
1 – point marker
...
parameters of further markers
…
reserved
