SVAN 979 User Manual - Appendixes
Table B.1.14. Profile parameters (block exists only inside the main block - see Table B.1.13Błąd! Nie można
odnaleźć źródła odwołania.)
Word
number
Name
Comment
0
0nn06h
06h = block identifier
0nnh = block length in words
1
Detector
type of exponential detector in vibration measurement mode:
0 – 100 ms time constant detector
1 – 125 ms time constant detector
2 – 200 ms time constant detector
3 – 500 ms time constant detector
4 – 1 s time constant detector
5 – 2 s time constant detector
6 – 5 s time constant detector
7 – 10 s time constant detector
type of exponential detector in sound measurement mode:
0 – Impulse
1 – Fast
2 – Slow
2
Filter
measurement filter in vibration measurement mode:
-3 – R3
-2 – R2
-1 – R1
0 – HP
1 – HP1
2 – HP3
3 – HP10
4 – Vel1
5 – Vel3
6 – Vel10
7 – VelMF
8 – Dil1
9 – Dil3
10 – Dil10
21 – Wh
measurement filter in sound measurement mode:
-3 – R3
-2 – R2
-1 – R1
1 – Z
2 – A
3 – C
4 – G
5 – B
