255
SVAN 979 User Manual - Appendixes
Table B.3.13. STIPA results
Word
number
Name
Comment
0
0061h
61h = block identifier
1
BlockLength
block length in words
2
STI
STI result in the format 0.01dB
3
LAeq
LAeq result in the format 0.01dB
4
LCeq
LCeq result in the format 0.01dB
5
N
number of frequencies of the STIPA analysis
6
LZeq[1]
LZeq result number for the first frequency in the format 0.01dB
7
Err1[1]
m(f1) error flag for the first frequency (0,1)
8
Mf1[1]
m(f1) result value for the first frequency in the format 0.01
9
Err2[1]
m(f2) error flag for the first frequency (0,1)
10
Mf2[1]
m(f2) result value for the first frequency in the format 0.01
i*5+1
LZeq[i]
LZeq result number for the next frequency in the format 0.01 dB
i*5+2
Err1[i]
m(f1) error flag for the next frequency (0,1)
i*5+3
Mf1[i]
m(f1) result value for the next frequency in the format 0.01
i*5+4
Err2[i]
m(f2) error flag for the next frequency (0,1)
i*5+5
Mf2[i]
m(f2) result value for the next frequency in the format 0.01
N*5+6
Flags
bit 0 – underrange flag
bit 1 – overload flag
N*5+7
STI-Measured
STI result not considering Ambient Noise
…
reserved
Table B.3.14. STIPA Ambient noise results
Word
number
Name
Comment
0
0062h
62h = block identifier
1
BlockLength
block length in words
2
N
number of frequencies of the STIPA analysis
3..
Distortion[N]
STIPA Ambient noise table in the format 0.01 dB
…
reserved
Table B.3.15. Wyniki pomiarów RT60
Word
number
Name
Comment
0
00xxh
0xxh = block identifier:
1Bh – instantaneous results,
1Ch – averaged results
1
BlockLength
block length in words
2
ReferenceFreq
reference frequency in 0.01 Hz format (nominal value)
3
reserved
