Svantek SVAN 979 - Page 256

256
SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
4
Ntot
total number of summary results; Total results are calculated with the
following filters:
Total[1] – measured with filter A
Total[2] – measured with filter C
Total[3] – measured with filter Z
5
NF1
index of the lower analysis frequency related to the reference
frequency
6
NF2
index of the upper analysis frequency related to the reference
frequency
7
CalcFlag[1]
flag of the calculated results for the first frequency:
0 – no calculated results
1 – results calculated
8
EDT[1]
EDT result value for the first frequency in milliseconds
9
RT20[1]
RT20 result value for the first frequency in milliseconds
10
RT30[1]
RT30 result value for the first frequency in milliseconds
11
RTuser[1]
RTuser result value for the first frequency in milliseconds
12
N_EDT[1]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of EDT averaged results for the first frequency
13
N_RT20[1]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of RT20 averaged results for the first frequency
14
N_RT30[1]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of RT30 averaged results for the first frequency
15
N_RTuser[1]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of RTuser averaged results for the first frequency
6+i*9+1
CalcFlag[i]
flag of the calculated results for the next frequency:
0 – no calculated results
1 – results calculated
6+i*9+2
EDT[i]
EDT result value for the next frequency in milliseconds
6+i*9+3
RT20[i]
RT20 result value for the next frequency in milliseconds
6+i*9+4
RT30[i]
RT30 result value for the next frequency in milliseconds
6+i*9+5
RTuser[i]
RTuser result value for the next frequency in milliseconds
6+i*9+6
N_EDT[i]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of averaged EDT results for the next frequency
6+i*9+7
N_RT20[i]
in the instantaneous results block:
– reserved value
in the averaged results block:
– number of averaged RT20 results for the next frequency
