Calibration and Verification Teledyne API T703/T703U Calibrator Operation Manual

128

VIEWING O

GENERATOR CALIBRATION POINTS 6.2.2.

To view these calibration points, press:

SETUP X.X SECONDARY SETUP MENU

COMM VARS DIAG EXIT

Make sure that the

calibrator is in standby

mode.

SETUP X.X ENTER PASSWORD

8 1 8 ENTR EXIT

Toggle to enter the correct

PASSWORD

DIAG SIGNAL I/O

PREV NEXT ENTR EXIT

DIAG O3 GEN CALIBRATION

PREV NEXT ENTR EXIT

Continue pressing NEXT until ...

DIAG O3 GEN CALIBRATION

CAL PNTS EXIT

Toggle to move between

calibration points

DIAG O3GEN 1) 500 MV, 5.0 MIN, ON

PREV NEXT INS DEL EDIT PRNT EXIT

STANDBY ACT =STANDBY

<TST TST> GEN STBY SEQ SETUP

SETUP X.X PRIMARY SETUP MENU

O3 SEQ CFG CLK PASS MORE EXIT

07223D DCN7107
