Teledyne API T703/T703U Calibrator Operation Manual Operating the Calibrator
81
AIN CALIBRATION 4.9.3.
This is the sub-menu to calibrate the instrument‟s A-to-D conversion circuitry.
This calibration should only be necessary after major repair such as a replacement
of CPU, motherboard or power supplies.
To perform an AIN CALIBRATION, press:
From the
AIO CONFIGURATION SUBMENU
DIAG ANALOG I/O CONFIGURATION
PREV NEXT ENTR EXIT
Continue pressing SET> until ….
DIAG AIO AIN CALIBRATED: NO
<SET CAL EXIT
DIAG AIO CALIBRATING A/D ZERO
DIAG AIO CALIBRATING A/D SPAN
DIAG AIO AIN CALIBRATED: YES
<SET CAL EXIT
DIAG AIO AOUTS CALIBRATED: NO
SET> CAL EXIT
To Next Page
