Operating the Calibrator Teledyne API T703/T703U Calibrator Operation Manual
48
Naming a Sequence 4.5.1.2.
The first step of creating a calibration sequence is to assign it a name. The name
can be up to 10 characters and can be comprised of any alpha character (A to Z),
and numeral (0 to 9) or the underscore character (“_“).
To assign a name to a sequence, press,
SETUP X.X NAME:[0]
<CH CH> INS DEL [0] ENTER EXIT
EXIT discards the
new NAME
ENTR accepts the
new NAME
Toggle to cycle through
the range of numerals
and available characters:
(“A – Z”; “0 – 9” & “ _ ”)
Moves the
cursor one
character left or
right.
Deletes a
character at the
cursor location.
Inserts a new a
character at the
cursor location.
STANDBY ACT CAL=0.000 LPM
<TST TST> GEN STBY SEQ SETUP
Make sure that the
calibrator is in standby
mode.
SETUP X.X PRIMARY SETUP MENU
GAS SEQ CFG CLK PASS MORE EXIT
SETUP X.X SEQUENCE CONFIGURATION
EDIT PRINT EXIT
SETUP X.X END OF SEQUENCES
INS PRNT EXIT
SETUP X.X 1) SEQ [NAME], [X] STEPS
PREV NEXT INS DEL EDIT PRNT EXIT
SETUP X.X NAME:0
SET> EDIT EXIT
Deletes the sequence shown
in the message field
Edits the sequence shown
in the message field
Scrolls back and forth between
existing sequences
This display only appears if there are no sequences currently
programmed into the calibrator.
OTHERWISE ...
To Next Page
