TELEDYNE API T703U - Performing an Automatic Calibration of the Ogenerator

To Next Page

To Previous Page

Calibration and Verification Teledyne API T703/T703U Calibrator Operation Manual

132

PERFORMING AN AUTOMATIC CALIBRATION OF THE O

6.2.6.

GENERATOR

To run the automatic O

generator calibration program, press:

Test runs automatically

STANDBY ACT =STANDBY

<TST TST> GEN STBY SEQ SETUP

Make sure that the

calibrator is in standby

mode.

SETUP X.X PRIMARY SETUP MENU

O3 SEQ CFG CLK PASS MORE EXIT

SETUP X.X SECONDARY SETUP MENU

COMM VARS DIAG EXIT

SETUP X.X ENTER PASSWORD

8 1 8 ENTR

EXIT

Toggle to enter the correct

PASSWORD

DIAG SIGNAL I/O

PREV NEXT ENTR EXIT

DIAG O3 GEN CALIBRATION

PREV NEXT ENTR EXIT

Continue pressing NEXT until ...

DIAG O3 GEN CALIBRATION

CAL

PNTS EXIT

DIAG O3 GEN CAL 0% COMPLETE

EXIT

DIAG O3 GEN CAL 100% COMPLETE

EXIT aborts

the calibration

07223D DCN7107
