To access and navigate the VARS menu, use the following menu button
sequence:
DO NOT CHANGE
these settings unless
specifically instructed to by
Teledyne API’s Customer
Service personnel.
STANDBY ACT =STANDBY
<TST TST> GEN STBY SEQ SETUP
Make sure that the
calibrator is in standby
mode.
SETUP X.X PRIMARY SETUP MENU
O3 SEQ CFG CLK PASS MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG EXIT
SETUP X.X ENTER PASSWORD
8 1 8 ENTR
EXIT
Toggle to enter the correct
PASSWORD
SETUP X.X 0) O3_PHOTO_LAMP=58.0 DegC
NEXT
JUMP EDIT PRNT EXIT
SETUP X.X 1) O3_PHOT_LAMP=58.0 DegC
PREV NEXT
JUMP EDIT PRNT EXIT
SETUP X.X 2) O3_CONC_RANGE=500.0 PPB
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X O3_CONC_RANGE=500.0 PPB
0 0 5 0 0 .0 ENTR EXIT
Toggle these bottons to set
the upper span point of the
O3_PHOTO_CONC
Test
Channel signal
In all cases:
EXIT discards the new
setting
ENTR accepts the
new setting
SETUP X.X 3) O3_PHOTO_BENCH_ONLY=OFF
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X O3_PHOTO_BENCH_ONLY=OFF
OFF 0 ENTR EXIT
Toggle to turn this mode
ON / OFF
SETUP X.X 4) ZA_PUMP_ENAB=ON
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X ZA_PUMP_ENAB=ON
ON ENTR EXIT
Toggle to turn this mode
ON / OFF
DO NOT CHANGE
these settings unless
specifically instructed to by
Teledyne API’s Customer
Service personnel
SETUP X.X 5) STD_TEMP=25.0 DegC
PREV NEXT
JUMP EDIT PRNT EXIT
SETUP X.X 6) STD PRESS=29.92 In-Hg
PREV NEXT
JUMP EDIT PRNT EXIT
SETUP X.X 7) CLOCK_ADJUST=0 Sec/Day
PREV JUMP EDIT ENTR EXIT
SETUP X.X CLOCK_ADJUST=0 Sec/Day
+
0 0 ENTR EXIT
Enter sign and number of
seconds per day the clock
gains (-) or loses(+)
4.11. OPERATING THE CALIBRATOR AS AN O
3
PHOTOMETER
The T703/T703U can easily be configured to measure an external source of
ozone.
07223D DCN7107
