Introduction Teledyne API T703/T703U Calibrator Operation Manual
16
1.2. OPTIONS
For mounting the analyzer in standard 19” racks
Rack mount brackets with 26 in. (660 mm) chassis slides
Rack mount brackets with 24 in. (610 mm) chassis slides
The T703/T703U WEIGHS about 16.3 kg (36 pounds). To avoid personal injury we recommend
two persons lift and carry the calibrator.
Disconnect all cables and tubing from the calibrator before carrying it.
Spare parts and expendables for 1-year operation
For remote serial, network and Internet communication with the analyzer.
Shielded, straight-through DB-9F to DB-25M cable, about 1.8 m long. Used to
interface with older computers or code activated switches with DB-25 serial
connectors.
Shielded, straight-through DB-9F to DB-9F cable of about 1.8 m length.
Patch cable, 2 meters long, used for Internet and LAN communications.
Cable for direct connection between instrument (rear panel USB port) and
personal computer.
For rear panel connection to personal computer.
Multidrop/LVDS card seated on the analyzer‟s CPU card.
Each instrument in the multidrop network requires this card and a communications cable
(Option 60B).
External Valve Driver Capability - For driving up to eight, 8-watt valves
12V External Valve Driver Capability
24V External Valve Driver Capability
NIST Traceable, Primary Standard Certification for use as a Primary Ozone Standard if purchased with the O
3
generator and photometer options, 1A and 2A, respectively.
Calibration as a Transfer Standard (6x6)
The Model T703 can be used as a Primary Ozone Standard. For this application the performance of the T703 Photometric
Calibrator is calibrated to Standard Reference Photometer (SRP) Calibrators ordered with this option are verified and
validated in accordance with the procedures prescribed by the U.S. Environmental Protection Agency (EPA) under Title 40
of the Code of Federal Regulations, Part 50, Appendix D (40 CFR Part 50).
Built in features, software activated
Maintenance Mode Switch, located inside the instrument, places the analyzer in
maintenance mode where it can continue sampling, yet ignore calibration, diagnostic, and
reset instrument commands. This feature is of particular use for instruments connected to
Multidrop or Hessen protocol networks.
Call Technical Support for activation.
Second Language Switch activates an alternate set of display messages in a language
other than the instrument‟s default language.
Call Technical Support for a specially programmed Disk on Module containing the second language.
