Teledyne API T703/T703U Calibrator Operation Manual Operating the Calibrator

Setting the Repeat Count for a Sequence 4.5.1.3.

The sequence can be set to repeat a certain number of times, from 1 to 100. It can

also be set to repeat indefinitely by inputting a zero (0) into the REPEAT

COUNTER.

To set the REPEAT COUNTER, press:

SETUP X.X REPEAT COUNT:1

<SET SET> EDIT EXIT

SETUP X.X NAME:[0]

0 0 1 ENTER EXIT

EXIT discards the

new NAME

ENTR accepts the

new NAME

Toggle these buttons to set the repeat count from 1 to 100.

Enter “0” to cause the sequence to loop indefinitely

Continue pressing SET> until ...

STANDBY ACT =STANDBY

<TST TST> GEN STBY SEQ SETUP

Make sure that the

calibrator is in standby

mode.

SETUP X.X PRIMARY SETUP MENU

O3 SEQ CFG CLK PASS MORE EXIT

SETUP X.X SEQUENCE CONFIGURATION

EDIT PRINT EXIT

SETUP X.X END OF SEQUENCES

INS PRNT EXIT

SETUP X.X 1) SEQ [NAME], [X] STEPS

PREV NEXT INS DEL EDIT PRNT EXIT

SETUP X.X NAME:0

SET> EDIT EXIT

Deletes the sequence shown

in the message field

Edits the sequence shown

in the message field

Scrolls back and forth between

existing sequences

This display only appears if there are no sequences currently

programmed into the calibrator.

OTHERWISE ...
