Teledyne API - Models T703, T703U, 703E MENU TREES (05745F DCN7107) APPENDIX A-1: Software Menu Trees
A-3
APPENDIX A-1: Software Menu Trees
See PRIMARY SETUP Menu
MAIN MENU

Press to
cycle
through the
active
warning
messages.
Press to
clear an
active
warning
messages.
Cycles
through
existing
calibration
sequences.
Press to cause calibrator to
enter STANDBY mode
MSG
1
STBY SEQ
2
CLR
1
SETUPGENTEST
1
1
Only appears when warning messages are active.
2
Only appears when an one or more calibration
sequences are programmed into the calibrator’s
memory.
PREV NEXT
<TST TST>
AUTO
GENERATE GENERATE:ZERO
ZERO ENTR EXIT
GENERATE GENERATE:0 PPB O3
0 0 0 0 PPB O3 ENTR EXIT
PPB
MGM
UGM
PCT
PPT
PPM
Toggle these buttons to set
the target concentration of
the calibrator output for this
gas
Toggles to switch
to O
3
generation
 O3GEN FRAC=[Value] (T703U only)
 O3 PRES=[Value] PSIG
 A-O3=[Value]
 T-O3=[Value]
 OUT FLW=[Value] LPM
 REG PRES=[Value] PSIG
 BOX TMP=[Value]ºC
 O3GENDRV=[Value] MV
 O3LAMPTMP=[Value]ºC
 PH MEAS[Value] MV
 PH REF=[Value] MV
 PH FLW=[Value] LPM
 PH LTEMP=[Value]ºC
 PH SPRES=[Value] IN-HG-A
 PH STEMP=[Value]ºC
 PH SLOPE=[Value]
 PH OFFST=[Value] PPB
 PH STAB=[Value] PPB
 TIME=[HH:MM:SS]
Figure A-1: Main Menu
