TELEDYNE API T703U - Page 241

Appendix C
Warranty/Repair Questionnaire
T703, T703U, 703E
(05747E DCN7107)
Teledyne API Technical Support
Email: sda_techsupport@teledyne.com
PHONE: (858) 657-9800 TOLL FREE: (800) 324-5190 FAX: (858) 657-9816
C-1
CUSTOMER: _______________________________ PHONE: _____________________________________
CONTACT NAME: ___________________________ FAX NO. _____________________________________
SITE ADDRESS: ____________________________________________________________________________
MODEL TYPE: _______________ SERIAL NO.: _________________ FIRMWARE REVISION: _____________
Are there any failure messages? ________________________________________________________________
__________________________________________________________________________________________
___________________________________________________________________________________________
___________________________________________________________________________________________
_________________________________________________________________________ (Continue on back if necessary)
PLEASE COMPLETE THE FOLLOWING TABLE:
PARAMETER
RECORDED VALUE
ACCEPTABLE
VALUE
Name in E-Series software
versions prior to v.C.1
Name in T-Series and in E-Series
w/software v. C.1 and higher.
ACT
ACT
PPB
1% OF TARG
TARG
TAR
PPB
50 – 1000 PPB
OUTPUT FLOW
OUT FLW
LPM
2 – 5 LPM
REG PRESSURE
REG PRES
PSIG
15 ± 2 PSIG @ 5 LPM
(n/a)
O3 PRES
1, 2
(703U only)
PSIG
8 ± 1 PSIG @ 5 LPM
BOX TEMP
BOX TMP
ºC
20 – 35 ºC
O3 GEN REF
2
O3GEN REF
2
mV
0 – 5000 mV
O3 GEN DRIVE
2
O3GENDRV
2
mV
0 – 5000mV
O3 LAMP TEMP
2
O3LAMPTMP
2
ºC
48 ± 1 ºC
PHOTO MEASURE
2
PH MEAS
2
mV
2500 – 4700 mV
PHOTO REFERENCE
2
PH REF
2
mV
2500 – 4700 mV
PHOTO FLOW
2
PH FLW
2
LPM
0.720 – 0.880 LPM
PHOTO LAMP TEMP
2
PH LTEMP
2
ºC
58 ± 1 ºC
PHOTO SPRESS
2
PH SPRES
2
IN-HG-A
-1” AMBIENT IN-HG-A
PHOTO STEMP
2
PH STEMP
2
ºC
25 – 48ºC
PHOTO SLOPE
2
PH SLOPE
2
1 ± 0.15
PHOTO OFFSET
2
PH OFFST
2
PPB
0 ± 10 PPB
(n/a)
PH STAB
2
PPB
<1 ppb on Zero Air
NOTE: Depending on options installed, not all test parameters shown will be available in your calibrator.
1
Ozone Regulator Pressure
2
If applicable option installed.
What is measured photometer flow rate _____________________________________________________ cc
3
/min
07223D DCN7107
