Operating the Calibrator Teledyne API T703/T703U Calibrator Operation Manual

From the

AIO CONFIGURATION SUBMENU

DIAG AIO TEST_OUTPUT: 5V, OVR, NOCAL

<SET SET> EDIT EXIT

Continue pressing SET> until ...

DIAG AIO TEST_OUTPUT: CALIBRATED:NO

<SET SET> CAL EXIT

DIAG AIO TEST_OUTPUT: RANGE: 5V

SET> EDIT EXIT

DIAG AIO AUTO CALIBRATING TEST_OUTPUT

DIAG AIO TEST_OUTPUT: CALIBRATED: YES

<SET SET> CAL EXIT

DIAG ANALOG I/O CONFIGURATION

PREV NEXT ENTR EXIT

Continue pressing SET> until you reach the

output to be configured

DIAG AIO AOUTS CALIBRATED: NO

SET> CAL EXIT
