227
APPENDIX 1
• Fundus Grabber setting
* Select "OCTSet (TOP-OCT Configurationi)", "General" and "Export Directory". Then, set this item.
• Export data setting captured on FastMap
* Select "OCTSet (TOP-OCT Configurationi)", "General" and "Export Directory". Then, set this item.
Item Contents of setting
Grabber Setting
Press the [Grabber Setting] button, and the system shifts to the "OCT Fun-
dus Grabber Setup" screen on P.52.
Export
Set export from Fundus Grabber.
Select "Not export". Export is not performed from Fundus Grabber.
Select "When capturing". When taking a picture with Fundus Grabber, the
image file is output to the folder specified by "[Fundus Capture Image] -
[Auto]" (*).
Select "When saving". When saving a picture with Fundus Grabber, the
image file is output to the folder specified by "[Fundus Capture Image] -
[Auto]" (*).
Item Contents of setting
When
Set export in OCT photography.
Select "Not export". DB registration and export are not done for the FastMap
fundus image.
Select "When capturing". When taking a picture, the FastMap image is out-
put to "FastMap Image" (*) 1 folder.
Select "When saving". When saving a picture, the FastMap image is output
to "FastMap Image" (*) 1 folder.
Action
Set the operation for export in OCT photography.
Select "Save on DB". The data is output to DB of IMAGEnet.
Select "Export". The data is output to "FastMap Image" (*) 1 folder.
Select "Save on DB & Export". The data is output to both DB of IMAGEnet
and "FastMap Image" (*) 1 folder.
Adopt capture mode
Select "Fundus photography". If "Use FDS format for Color fundus photogra-
phy" is selected, DB registration and export are valid when taking a color pic-
ture of fundus.
Select "OCT + Fundus Image". DB registration and export for color fundus
are valid in OCT photography.
Trimming
Set "On" for this item. Trimming is done for the color fundus image. (The
black part without the color fundus image is deleted.)
To Next Page
