CAPTURING TOMOGRAMS
(8) T
rimming Set
Set trimming in the following dialog box.
Information
Contents
Setting of Color/F
A picture angle
Only
when
a
check
ma
rk is placed for angle, the setting
is vali-
dated.
Setting
of F
AF trimming
When this item is va
lidated, trimming is performed with the com-
pensation value of the instrument bod
y
.
Setting of Color/F
A picture angle
Setting of F
AF trimming
