FilteringtheClosed-loopTractionCircuit(continued)
B.Ifarearwheelmotorwasreplaced,thoroughlycleanthejunctionof
thebulkheadttingandhydraulichoseasshowninFigure45,then
disconnectthehosefromthebulkheadtting.
g299738
Figure45
1.Leftsidebulkheadtting3.Rightsidebulkheadtting
2.Leftrearwheelmotorsupplyhose
4.Rightrearwheelmotorsupplyhose
IMPORTANT
Ifusingahydrauliclterthatisnotbidirectional,installthelter
withtheowdirectiontowardthetractionpumpforatractionpump
failure,andtowardthewheelmotorsforawheelmotorfailure.
5.ConnecttheTorohighowhydrauliclterinseriesbetweenthedisconnected
ttingsandtubeorhose.Usethehydraulichosekittoconnectthelterto
themachineifnecessary;refertoHydraulicHoseKit(page2–16).Ensure
thatallhydraulicconnectionsareproperlytightened.
HydraulicSystem:ServiceandRepairs
Page5–58
