RemovingandInstallingtheBattery(continued)
7.Cleanthebatterytray.Neutralizeandrenishanydamagedareasofthe
batterytray.
8.Inspectthebatterycablesandconnectorsfordamageandcorrosion.Clean,
repair,orreplacethebatterycablesandconnectorsifnecessary.
9.Installthebatteryinthereverseorder:
IMPORTANT
Topreventpossibleelectricalproblems,installonlyafully
chargedbattery.
A.Connectthepositive(+)cableconnectorontothepositive(+)battery
terminal.
B.Connectadigitalmultimeter(settoA)betweenthenegative(-)battery
postandthenegative(-)cableconnector.Ensurethatthereadingisless
than0.1A.Areadingofmorethan0.1Ausuallyindicatesadamaged
switch,ashortedcircuit,orgroundedwire.Identifyandrepairthe
electricalfaultsbeforereturningthemachinetoservice.
C.Connectthenegative(-)cableconnectortothenegative(-)battery
terminal.Thecableclampmustbeparalleltotheedgeofthebattery
beforesecuringtheclamp.
10.Afteryoumaketheconnections,applybatteryterminalprotectorT oroPart
No.107-0392oralightlayerofpetroleumjellytothebatteryterminalsand
cableconnectors.
11.Makesurethattherubberbootsareinplaceoverthepositivecableendat
thebatterypostandatthestarter.
Inspecting,Maintaining,andTestingtheBattery
TemperatureCorrectingSpecicGravity
CellTemperature100°F
CellSpecicGravity
1.245
38°Cminus27°Cequals11.0°C
(100°Fminus80°Fequals20°F)
11°Cmultiplyby0.004/5.5°Cequals0.008
(20°Fmultiplyby0.004/10°Fequals0.008)
ADD(conversionabove)
0.008
Correctionto27°C(80°F)
1.253
MinimumVoltage
MinimumVoltageBattery-ElectrolyteTemperature
9.6
70°F(andup)21°C(andup)
9.5
60°F15°C
9.4
50°F10°C
9.3
40°F4°C
9.1
30°F-1°C
Groundsmaster
®
3200,3300and3310
Page6–65
