9-6 Qualitek mR Owner’s Guide
9.3.3 System Status: Health
9.3.4 Test Setup: Specification
The following resisters are updated in real-time when each program begins to run.
9.3.5 Test Status: Counters
Input
Register
s
Address
(decimal)
Name/description of 16-bit values
30009 9 Heartbeat - sequences from 1 to n incrementing at 1
second intervals (unsigned short).
Input
Registers
Address
(decimal)
Name/description of 16-bit values
30010 10 Program Number – 1 to 127 (unsigned short)
30011 11 Program Name – 18 registers (null-terminated 36
character string)
30029 29 Test Type – enum code (see Table 2)
Input
Registers
Address
(decimal)
Name/description of 16-bit values
30030 30 Test Counter – All, 2 registers (unsigned long)
30032 32 Test Counter – Pass, 2 registers (unsigned long)
30034 34 Test Counter – Fail, 2 registers (unsigned long)
30036 36 Test Counter – Salvage, 2 registers (unsigned long)
