9-8 Qualitek mR Owner’s Guide
9.3.7 Test Status: Results
* Initial value at start of measurement step.
9.3.8 Test Setup: Inquire Specification
The following registers are Program #n Specifications and are updated in response
when 40039 register (inquire program #n) is written.
Input
Registers
Address
(decimal)
Name/description of 16-bit values
30072 72 Audit Log, 128 registers (up to 256 character null-
terminated string)
30200 200 Context – Cycle Number, 2 registers (unsigned long)
30202 202 Time Stamp, 16 registers (32 character null-terminated
string)
30218 218 Program Number, 1 to 127 (unsigned short)
30219 219 Test Type, enum code (see Table 2)
30220 220 Channel Number
30221 221 Applied Units, enum code (see Table 3)
30222 222 Applied Value (float)*
30224 224 Result Units, enum code (see Table 3)
30225 225 Result Value (float)
30227 227 Test Code, enum code (see Table 4)
30228 228 Fail/Abort Code, enum code (see Table 5 or Table 6)
30229 229 Test Step Type, enum code (see Table 7)
30230 230 Measure Value [used for comp/cal] (float)
30232 232 Measure Units (see Table 3)
Input
Registers
Address
(decimal)
Name/description of 16-bit values
30233 233 Fill/Evac 1 Target (float)
30235 235 Fill/Evac 2 Target (float)
30237 237 Fill/Evac 1 Min Reject (float)
