9-20 Qualitek mR Owner’s Guide
Table 7 – Default Holding Register Setup
30093 93 Limits - Max (float)
30095 95 Compensation value [master with no leak decay] (float)
30097 97 Calibration Leak Rate (float)
30099 99 Calibration value [master with leak decay] (float)
Holding
Registers
Address
(decimal)
Name/description of 16-bit values
40001 1 Start, Abort - tester control (Boolean packed binary)
Bit0 – Start
Bit1 – Abort
40002 2 Set Program by Number (1 to 127 are valid)
Program #n Specifications to be set when 40040 command is written
40003 3 Fill/Evac 1 Target (float)
40005 5 Fill/Evac 2 Target (float)
40007 7 Fill/Evac 1 Min Reject (float)
40009 9 Fill/Evac 1 Max Reject (float)
40011 11 Fill/Evac 2 Min Reject (float)
40013 13 Fill/Evac 2 Max Reject (float)
40015 15 Fill/Evac 1 timer (float)
40017 17 Fill/Evac 2 timer (float)
40019 19 Isolate timer (float)
40021 21 Stabilize timer (float)
40023 23 Measure timer (float)
40025 25 Vent timer (float)
40027 27 Limits - Min 1 (float)
40029 29 Limits - Middle (float)
40031 31 Limits - Max (float)
40033 33 Compensation value [master with no leak decay] (float)
