General Troubleshooting 4-11
Clutch Tests Tests functionality of clutches by activating one clutch at a time.
Take-Away Clutch Clutch On
Clutch Off
All tests are activated by pressing
OK.
Listen for the clutch.
Test times out after 1 second.
Developer Clutch Clutch On
Clutch Off
Registration Clutch Clutch On
Clutch Off
Duplex Clutch Which Direction?
CCW
CW
Clutch On
Clutch Off
Finisher Clutches Decurler Cam Clutch
Clutch On
Clutch Off
Solenoid Tests Tests functionality of the solenoids by activation one solenoid at a time.
Exit Gate Solenoid Solenoid On
Solenoid Off
Duplex Gate
Solenoid
Solenoid On
Solenoid Off
Shutter Solenoid Solenoid On
Solenoid Off
Press OK to run test.
ADC Shutter Open Solenoid On ADC = Automatic Density
Correction
Press OK to run test.
ADC Shutter Close Solenoid Off ADC = Automatic Density
Correction
Press OK to run test.
Tray 1/ MPT Feed
Solenoid
Solenoid On
Solenoid Off
MPT = Multi-Purpose Tray
Press OK to run test.
Finisher Solenoids Set Clamp Paddle
HTrans Gate In Open
HTrans Gate In Close
Press OK to run test.
Adjustments/ Calibrations Performs adjustments, calibrations and operations essential to
the performance of the printer. For details on performing the RegiCon procedures, see
"RegiCon Adjustment Procedures" on page 6-5.
Belt Edge Learn OK or Failed
ATC Sensor Setup See to "ATC Sensor Setup" on
page 6-14.
TRC Adjust Displaces toner rendering curve
points, not technician adjustable.
