Xerox WorkCentre 5230

February, 2008
6-38
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
715-632 TX_BW_Copy_Fax Suppression Level of AE
(Normal, Pencil Text)
0 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF. 8bit~11bit, CVT or DADF 2 Sided Copy (* Used as the PreIPS EAER_DAT suppression level
as well)
715-633 TX_BW_Copy_Fax Offset Level of AE (Normal,
Pencil Text)
273 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy
715-634 TPL_BW_Copy_Fax Suppression Level of AE
(Light Document)
0 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy (* Used as the PreIPS EAER_DAT suppression level
as well)
715-635 TPL_BW_Copy_Fax Offset Level of AE (Light
Document)
273 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy
715-636 TRP_BW_Copy_Fax Suppression Level of AE
(Tracing Paper)
0 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy (* Used as the PreIPS EAER_DAT suppression level
as well)
715-637 TRP_BW_Copy_Fax Offset Level of AE (Tracing
Paper)
273 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy
715-638 TP_CL_Copy Removal Level of AE 0 0~4095 0: Strength level 0 (standard), 1: Strength level 1, 2: Strength level 2, 3: Strength level 3, 4: Strength
level 4, 5or more: Strength level 0 (standard)
0 to 3 bits: Platen
4 to 7 bits: CVT or machines with DADF
8 to 11 bits: CVT or machines with DADF (duplex copy)
Coordination with TOOLS to determine the parameter selection level by adding the value for
TOOLS (level 0 to 4) and the level number of this NVM (0 to 4). When the result is level 4 or higher,
the level is 4. (Also applies to removal level of PreIPS EAER_DAT.)
715-639 TP_CL_Copy Offset Level of AE 0 0~4095 0: Strength level 0 (standard), 1: Strength level 1, 2: Strength level 2, 3: Strength level 3, 4: Strength
level 4, 5or more: Strength level 0 (standard)
0 to 3 bits: Platen
4 to 7 bits: CVT or machines with DADF
8 to 11 bits: CVT or machines with DADF (duplex copy)
715-640 TX_CL_Copy Removal Level of AE 0: Strength level 0 (standard), 1: Strength level 1, 2: Strength level 2, 3: Strength level 3, 4: Strength
level 4, 5or more: Strength level 0 (standard)
0 to 3 bits: Platen
4 to 7 bits: CVT or machines with DADF
8 to 11 bits: CVT or machines with DADF (duplex copy)
Coordination with TOOLS to determine the parameter selection level by adding the value for
TOOLS (level 0 to 4) and the level number of this NVM (0 to 4). When the result is level 4 or higher,
the level is 4. (Also applies to removal level of PreIPS EAER_DAT.)
715-641 TX_CL_Copy Offset Level of AE 0 0~4095 0: Strength level 0 (standard), 1: Strength level 1, 2: Strength level 2, 3: Strength level 3, 4: Strength
level 4, 5or more: Strength level 0 (standard)
0 to 3 bits: Platen
4 to 7 bits: CVT or machines with DADF
8 to 11 bits: CVT or machines with DADF (duplex copy)
Table 2 IISS
Chain-Link Content Default Range Meaning
