February, 2008
6-66
WorkCentre 5225, 5230
Launch Version
General Procedures
840-031 Switch System of ServerFax and Enbed-
dedFax
1 1~2 1: Priority on Server Fax, 2: Priority on Analog Fax
840-032 ServerFax Confirmation Sheet Control 2 1~3 1: Always output report, 2: Output report only when error occurs, 3: Do not output report
840-034 ServerFax Transfer Protocol 1 1~5 1: FTP, 2: NCP, 3: SMB, 4: SMTP, 5: HTTP
840-041 SMB Browsing Timeout Setting 5 1~300 1 to 300 seconds
840-046 Use cn for LDAP Search Filter 1 1~2 1: On, 2: Off
840-047 Use sn for LDAP Search Filter 2 1~2 1: On, 2: Off
840-048 Use givenname for LDAP Search Filter 2 1~2 1: On, 2: Off
840-049 Use custom attribute for LDAP Search Fil-
ter
2 1~2 1: On, 2: Off
840-080 ABL LDAP Valid 1 0~1 1: Allow, 0: Prohibit
840-081 ABL LDAP CN cn Character string within 32bytes.
840-082 ABL LDAP SN sn Character string within 32bytes.
840-083 ABL LDAP Given Name given name Character string within 32bytes.
840-084 ABL LDAP Mail mail Character string within 32bytes.
840-085 ABL LDAP Alt Name1 Telephone number (FX
default)
Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-086 ABL LDAP Alt Name1 Type Telephone number Character string within 32bytes.
840-087 ABL LDAP Alt Name2 Office (FX default) Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-088 ABL LDAP Alt Name2 Type o Character string within 32bytes.
840-089 ABL LDAP Alt Name3 Department (FX default) Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-090 ABL LDAP Alt Name3 Type ou Character string within 32bytes.
840-091 ABL LDAP Max Hit Count 50 5~100
840-092 ABL LDAP DN NULL Within 256bytes. Do not set if LDAP authentication is not required.
840-093 ABL LDAP Password NULL Within 32bytes. Do not set if password is not required in LDAP authentication.
840-094 ABL LDAP Root NULL Within 255bytes.
840-095 ABL LDAP Scope 3 1~3 1: Root entry only, 2: One level below root entry only, 3: All levels below root entry
840-096 ABL LDAP Object Class * Within 32bytes.
840-097 ABL LDAP Timeout 30 For 0 or 5~120 detected by the device, set the timeout value to a numerical value other than
0. If 0 is specified, the device will not detect timeout. The timeout setting will follow the set
-
ting in the Directory Server Service.
840-098 ABL LDAP Directory Application NULL 0~3 0: None (other application server that is not defined), 1: Microsoft (ActiveDirectory or
Microsoft ExchangeServer5.5), 2: Novel* NetWare5*, 3: IBM Domino 6*.
* Mapping of properties for retrieval and LDAP properties are done based on this setting.
840-104 Custom Attribute for LDAP Search Filter NULL Maximum of 32 bytes including null-terminated character string. Upper case and lower case
letters are distinguished. For this system data’s character string to be valid, “Use of Custom
LDAP Attribute Type” needs to be set to “On.”
840-115 Scan Template Management Enable 0 0~1 0: Do not enable, 1: Enable
840-116 Scan to E-Mail Net Config Sign 3 1~3 1: Always place signature, 2: Never place signature, 3: User selection
840-117 IFAX Net Config Sign 3 1~3 1: Always place signature, 2: Never place signature, 3: User selection
Table 6 Scan Service
Chain-
Link Content Default Range Meaning
To Next Page
