February, 2008
6-127
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
078-202 HCF Size Sensor A - Paper size Not Available
078-203 HCF Size Sensor B - Paper size Not Available
078-204 HCF Tray In Sensor H Tray inserted Not Available
078-205 HCF Level Sensor H Lift up Not Available
078-300 HCF Transport Interlock H Cover is open (Interlock Switch off) Not Available
078-301 HCF Side Out Switch H Open Not Available
089-100 Registration SENSOR L with paper Not Available
089-101 Registration SENSOR (DM) H with paper Sensor level detected by DM DM
089-200 Registration CLUTCH (DM) L in ON state Signal detected by DM MODULE DM
089-201 Registration CLUTCH(EXIT) L in ON state Signal detected by EXIT MODULE EXIT
091-200 DRUM DETECT L EP Cartridge installed Not Available
092-200 Temperature Sensor Analog Min 140, Max 710 Not Available
092-201 Humidity Sensor Analog Min 36, Max 400 Not Available
092-202 ATC Sensor Analog Min 200, Max 800 Not Available
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level
Meaning Timer Off Cycle Operation Remarks
012-013 Sub Paddle Solenoid ON/OFF L = ON Same as Name X X 100 ms (B/C-Finisher)
660 ms (A-Finisher)
250 ms (SB-Finisher)
012-018 Transport Motor Reverse ON/OFF - Same as Name X X Reverse rotation
012-020 Front Tamper Motor Low FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-021 Front Tamper Motor Middle FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-022 Front Tamper Motor High FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-023 Front Tamper Motor Low REAR ON/OFF Pulse ON Same as Name X X Not Available
012-024 Front Tamper Motor Middle REAR ON/
OFF
Pulse ON Same as Name X X Not Available
012-025 Front Tamper Motor High REAR ON/OFF Pulse ON Same as Name X X Not Available
012-026 Rear Tamper Motor Low FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-027 Rear Tamper Motor Middle FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-028 Rear Tamper Motor High FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-029 Rear Tamper Motor Low REAR ON/OFF Pulse ON Same as Name X X Not Available
012-030 Rear Tamper Motor Middle REAR ON/
OFF
Pulse ON Same as Name X X Not Available
012-031 Rear Tamper Motor High REAR ON/OFF Pulse ON Same as Name X X Not Available
012-032 Xport Motor 1 ON/OFF - Same as Name X X Forward rotation: highest speed
012-033 Xport Motor 2 ON/OFF - Same as Name X X Forward rotation: high speed
Table 1 Input Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Remarks
To Next Page
