February, 2008
6-128
WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
012-034 Xport Motor 3 ON/OFF - Same as Name X X Forward rotation: medium high speed
012-035 Xport Motor 4 ON/OFF - Same as Name X X Forward rotation: medium speed
012-036 Transport Motor 1 ON/OFF - Same as Name X X Forward rotation: high speed
012-037 Transport Motor 2 ON/OFF - Same as Name X X Forward rotation: medium speed
012-038 Transport Motor 3 ON/OFF - Same as Name X X Forward rotation: low speed
012-039 Xport Motor Reverse ON/OFF - Same as Name X X Reverse rotation
012-040 Stapler Move Motor Low FRONT ON/OFF - Same as Name X X Not Available
012-042 Stapler Move Motor High FRONT ON/OFF - Same as Name X X Not Available
012-043 Stapler Move Motor Low REAR ON/OFF - Same as Name X X Not Available
012-045 Stapler Move Motor High REAR ON/OFF - Same as Name X X Not Available
012-046 Staple Motor FORWARD ON/OFF H Same as Name X X Not Available
012-047 Staple Motor REVERSE ON/OFF H Same as Name X X Not Available
012-050 Set Clamp Clutch ON/OFF L = ON Set Clamp Paddle rotation X X 200 ms
012-051 Set Clamp Paddle - Same as Name X X Not Available
012-052 Eject Clamp Motor Up ON/OFF Pulse ON Eject Clamp Roller moves up X X Motor forward rotation: high speed
012-053 Eject Clamp Motor Down ON/OFF Pulse ON Eject Clamp Roller moves down X X Motor reverse rotation: high speed
012-054 Eject Motor Low Forward ON/OFF Pulse ON Same as Name X X Motor forward rotation: low speed
SB-Finisher: 1136 pulses
Other Finishers: 2000 pulses
012-055 Eject Motor High Forward ON/OFF Pulse ON Same as Name X X Motor forward rotation: high speed
SB-Finisher: 1136 pulses
Other Finishers: 2000 pulses
012-060 Stacker Motor UP ON/OFF H Same as Name X X Not Available
012-061 Stacker Motor DOWN ON/OFF H Same as Name X X Not Available
012-074 Puncher Motor home Pulse ON Puncher Motor moves to home posi-
tion
X X
012-077 2-Hole Puncher Motor ON/OFF H = ON 2-Hole Puncher Motor moves away
from home position
X X
012-078 3-Hole Puncher Motor ON/OFF H = ON 3-Hole Puncher Motor moves away
from home position
X X
012-079 4-Hole Puncher Motor ON/OFF H = ON 4-Hole Puncher Motor moves away
from home position
X X
012-080 Main Drive Motor ON/OFF L Same as Name X X Not Available
012-081 Eject Motor FORWARD ON/OFF - Same as Name X X Not Available
012-082 Eject Motor REVERSE ON/OFF - Same as Name X X Not Available
012-083 Eject Clamp Low DOWN - Same as Name X X Not Available
012-084 Eject Clamp Middle DOWN - Same as Name X X Not Available
012-085 Eject Clamp UP - Same as Name X X Not Available
012-086 Set Clamp Paddle Solenoid ON L Same as Name X X Not Available
013-022 Knife Motor Forward ON/OFF H = ON Same as Name X X
013-023 Knife Motor Reverse ON/OFF H = ON Same as Name X X
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
To Next Page
