February, 2008
6-129
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
013-024 Front Booklet Staple Motor Forward ON/
OFF
H = ON Same as Name X X
013-025 Front Booklet Staple Motor Reverse ON/
OFF
H = ON Same as Name X X
013-026 Rear Booklet Staple Motor Forward ON/
OFF
H = ON Same as Name X X
013-027 Rear Booklet Staple Motor Reverse ON/
OFF
H = ON Same as Name X X
013-028 Booklet Staple Move Motor IN Pulse ON Booklet Stapler moves to the IN side X X 350 pulses
013-029 Booklet Staple Move Motor OUT Pulse ON Booklet Stapler moves to the OUT
side
X X 350 pulses
042-001 MAIN MOTOR ON L Same as Name X X Not Available
042-002 FUSER FAN MOTOR (HIGH SPEED) - Fuser Fan changes from Low to High
Rotation.
X X Not Available
042-003 ROS FAN MOTOR ON L ROS Fan Motor Start & Stop X X Not Available
047-001 OFFSET MOTOR1 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-002 FUSER FAN MOTOR(HIGH SPEED) - Fuser Fan changes from Low to High
Rotation.
X X Not Available
047-003 OFFSET MOTOR2 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-004 OFFSET MOTOR2 REVERSE ROTA-
TION
- Same as Name X X EXIT
047-005 OFFSET MOTOR1 REVERSE ROTA-
TION
- Same as Name X X EXIT
047-006 MAIN MOTOR L Same as Name X X Not Available
047-022 EXIT DRIVE MOTOR FORWARD(Eject
Paper out)
- Same as Name X X Not Available
047-023 EXIT DRIVE MOTOR REVERSE(send
paper into Dup)
- Same as Name X X Not Available
047-024 EXIT GATE SOLENOID H Switch Gate to Exit2/FUT X X Not Available
047-025 FACE UP GATE SOLENOID L Switch FUT Gate to Face Up Tray X X EXIT
047-026 EXIT 2 FAN - Exit 2 FAN rotating X X Not Available
061-001 ROS MOTOR ON L ROS Motor Start & Stop X X Not Available
071-001 TRAY1 LIFTER UP(FEED MOTOR
Reverse)
- Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X Not Available
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
