GENERAL CHASSIS (1)
Removing the battery and leg shield assembly
Order Job/Parts to remove Q’ty Remarks
13 Auxiliary DC jack 1
14 Storage box 1
15 Protector 1
16 Storage compartment lid lock solenoid 1
17 Cover 1
FWDFWD
13
14
15
16
17
1.5 N・m (0.15 kgf・m, 1.1 lb・ft)
4.0 N・m (0.40 kgf・m, 3.0 lb・ft)
1.5 N・m (0.15 kgf・m, 1.1 lb・ft)
4.3 N・m (0.43 kgf・m, 3.2 lb・ft)
4.0 N・m (0.40 kgf・m, 3.0 lb・ft)
2.8 N・m (0.28 kgf・m, 2.1 lb・ft)
