Yamaha TMAX TECH MAX 2020 - Page 158

4-29
FRONT WHEEL
8. Install:
• Front brake caliper
• Front brake hose holder
WARNING
EWA13500
Make sure the brake hose is routed properly.
Front brake caliper bolt
35 N·m (3.5 kgf·m, 26 lb·ft)
Front brake hose holder bolt
(left)
9 N·m (0.9 kgf·m, 6.6 lb·ft)
Front brake hose holder bolt
(right)
7 N·m (0.7 kgf·m, 5.2 lb·ft)
1
1
2
2
a
G088903
T
R
.
.
