4-31
REAR WHEEL
Removing the rear brake disc and rear wheel pulley
Order Job/Parts to remove Q’ty Remarks
1 Rear brake disc 1
2 Rear wheel sensor rotor 1
3 Drive belt guide 1
4 Rear wheel pulley 1
5Rear wheel 1
1
2
3
45
LT
LT
LT
LT
8 N・m (0.8 kgf・m, 5.9 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
30 N・m (3.0 kgf・m, 22 lb・ft)
64 N・m (6.4 kgf・m, 47 lb・ft)
