4-103
SWINGARM
4. Tighten:
• Pivot shaft
• Pivot shaft nut
a. With your fingers, screw in the pivot shaft
until it touches the collar, and then tighten
the pivot shaft to the specified torque.
b. Tighten the pivot shaft nut to the specified
torque.
Swingarm bolt
40 N·m (4.0 kgf·m, 30 lb·ft)
Drive pulley assembly bolt
48 N·m (4.8 kgf·m, 35 lb·ft)
Pivot shaft
6 N·m (0.6 kgf·m, 4.4 lb·ft)
Pivot shaft nut
100 N·m (10 kgf·m, 74 lb·ft)
T
R
.
.
T
R
.
.
