5-29
VALVES AND VALVE SPRINGS
6. Lubricate:
• Valve pad
(with the recommended lubricant)
7. Lubricate:
• Valve lifter
(with the recommended lubricant)
8. Install:
• Valve pad
• Valve lifter
ECA22150
After making sure that the valve pads are ful-
ly inserted, install the valve lifter taking care
so that the pads do not fall.
• The valve lifter must move smoothly when ro-
tated with a finger.
• Each valve lifter and valve pad must be rein-
stalled in its original position.
Recommended lubricant
Molybdenum disulfide oil
Recommended lubricant
Engine oil
