Yamaha TMAX TECH MAX 2020 User Manual

5-74
CRANKSHAFT
Removing the connecting rods
Order Job/Parts to remove Q’ty Remarks
1 Connecting rod cap 2
2 Big end lower bearing 2
3 Connecting rod 2
4 Big end upper bearing 2
5 Piston pin clip 2
6 Balancer piston pin 1
7 Balancer piston 1
8 Balancer connecting rod cap 1
9 Balancer big end lower bearing 1
10 Balancer connecting rod 1
11 Balancer big end upper bearing 1
1
1
2
2
3
3
4
4
5
5
6
7
8
9
10
11
New
New
New
New
New
New
New
New
New
New
M
M
M
M
E
E
E
E
E
E
E
E
M
M
M
M
M
E
60 N
•
m (6.0 kgf
•
m, 44 lb
•
ft)
1st
2nd
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
Specified angle
120˚
1st
2nd
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
Specified angle
120˚
