6-2
COOLING SYSTEM DIAGRAMS
1
2
3
4
5
3
6
10
9 8 7
1. Thermostat
2. Cooling system air bleed hose
3. Coolant reservoir hose
4. Radiator cap
5. Radiator filler hose
6. Radiator
7. Radiator bracket
8. Radiator inlet hose
9. Oil cooler
10. Oil cooler inlet hose
