2-5
ENGINE SPECIFICATIONS
Clutch
Clutch type Wet, centrifugal, multiple-disc
Friction plate thickness 2.92–3.08 mm (0.115–0.121 in)
Plate quantity 6 pcs
Wear limit 2.82 mm (0.111 in)
Clutch plate 1 thickness 1.30-1.50 mm (0.051-0.059 in)
Plate quantity 5 pcs
Warpage limit 0.10 mm (0.004 in)
Clutch plate 2 thickness 1.80-2.00 mm (0.071-0.079 in)
Plate quantity 2 pcs
Warpage limit 0.10 mm (0.004 in)
Wear limit 1.75 mm (0.069 in)
Clutch spring free length 30.45 mm (1.20 in)
Limit 28.92 mm (1.14 in)
Clutch damper spring height 3.50 mm (0.14 in)
Minimum height 3.10 mm (0.12 in)
Spring quantity 7 pcs
Clutch spring plate height 4.70 mm (0.19 in)
Minimum height 4.40 mm (0.17 in)
Spring quantity 1 pcs
Clutch-in revolution 1650–2250 r/min
Clutch-stall revolution 3500–4500 r/min
V-belt
V-belt width limit 31.4 mm (1.24 in)
Drivetrain
Primary reduction ratio 1.000
Transmission type V-belt automatic
Transmission ratio 2.041–0.758 : 1
Weight outside diameter 25.0 mm (0.98 in)
Limit 24.5 mm (0.96 in)
Drive axle runout limit 0.08 mm (0.0032 in)
Secondary shaft runout limit 0.12 mm (0.0047 in)
Secondary reduction ratio 5.772 (52/32 x 36/23 x 59/26)
Final drive Belt
Air filter
Air filter element Oil-coated paper element
V-belt filter element Dry element
Fuel pump
Pump type Electrical
Maximum consumption amperage 1.7 A
Fuel injector
Resistance 12.0
Throttle body
ID mark B7M1
