CHASSIS SPECIFICATIONS
Rear brake
Type Hydraulic single disc brake
Disc outside diameter thickness 282.0 5.0 mm (11.10 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc runout limit (as measured on
wheel) 0.15 mm (0.0059 in)
Brake pad lining thickness limit 0.8 mm (0.03 in)
Master cylinder inside diameter 14.0 mm (0.55 in)
Caliper cylinder inside diameter 38.10 mm (1.50 in)
Specified brake fluid DOT 4
Front suspension
Type Telescopic fork
Spring Coil spring
Shock absorber Hydraulic damper
Wheel travel 120 mm (4.7 in)
Fork spring free length 287.8 mm (11.33 in)
Limit 282.0 mm (11.10 in)
Inner tube bending limit 0.2 mm (0.01 in)
Recommended oil Yamaha Suspension Oil 01
Quantity (left) 444.0 cm³ (15.01 US oz)
Quantity (right) 434.0 cm³ (14.67 US oz)
Level (left) 114 mm (4.5 in)
Level (right) 118 mm (4.6 in)
Rear suspension
Type Swingarm (link suspension)
Spring Coil spring
Shock absorber Gas-hydraulic damper
Wheel travel 117 mm (4.6 in)
Spring preload
Adjusting system Mechanical adjustable type (XP560D)
Unit for adjustment Cam position (XP560D)
Adjustment value (Soft) 7 (XP560D)
Adjustment value (STD) 4 (XP560D)
Adjustment value (Hard) 1 (XP560D)
Rebound damping
Adjusting system Mechanical adjustable type (XP560D)
Unit for adjustment Turn (XP560D)
Adjustment value from the start position
(Soft) 3 (XP560D)
Adjustment value from the start position
(STD) 1.25 (XP560D)
Adjustment value from the start position
(Hard) 0 (XP560D)
Drive belt
Drive belt vibration frequency 74–94 Hz
