2-10
ELECTRICAL SPECIFICATIONS
ABS warning light LED
Cruise control “SET” indicator light LED (XP560D)
Cruise control “ON” indicator light LED (XP560D)
Smart key system indicator light LED
Traction control system indicator light LED
Starter motor
Brush overall length limit 6.5 mm (0.26 in)
Brush spring force 6.02–6.51 N (614–664 gf, 21.69–23.45 oz)
Mica undercut (depth) 0.70 mm (0.03 in)
Fuel sender unit
Sender unit resistance (full) 10.0–14.0
Sender unit resistance (empty) 267.0–273.0
Grip warmer
Grip warmer resistance (L) 1.2–1.4
Grip warmer resistance (R) 1.2–1.5
Seat warmer
Rider seat resistance 8.8–10.8 (XP560D)
Fuel injection sensor
Crankshaft position sensor resistance 228–342
Intake air temperature sensor resistance 5400–6600 at 0 C (5400–6600 at 32 F)
Intake air temperature sensor resistance 290–390 at 80 C (290–390 at 176 F)
Atmospheric pressure sensor output voltage 3.59–3.67 V at 101.3 kPa (3.59–3.67 V at 1.01
kgf/cm², 3.59–3.67 V at 14.7 psi)
Coolant temperature sensor resistance 2513–2777 at 20 C (2513–2777 at 68 F)
Coolant temperature sensor resistance 210–221 at 100 C (210–221 at 212 F)
Fuse(s)
Main fuse 40.0 A
Headlight fuse 7.5 A
Taillight fuse 7.5 A
Brake light fuse 1.0 A (XP560D)
Signaling system fuse 7.5 A
Ignition fuse 7.5 A
Radiator fan motor fuse 15.0 A
Fuel injection system fuse 7.5 A
ABS control unit fuse 7.5 A
ABS motor fuse 30.0 A
ABS solenoid fuse 15.0 A
Cruise control fuse 1.0 A (XP560D)
Auxiliary DC jack fuse 2.0 A
Backup fuse 15.0 A
Windshield motor fuse 20.0 A (XP560D)
Electronic throttle valve fuse 7.5 A
Baggage fuse 7.5 A (XP560E)
