8-35
SIGNALING SYSTEM
3. Check the turn signal/hazard relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the turn signal/hazard relay.
OK
4. Check the entire signaling sys-
tem’s wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
NG
Properly connect or replace the wire har-
ness.
OK
Replace the meter assembly and/or
remote control unit.
The fuel meter fails to operate.
1. Check the fuel sender.
Refer to “CHECKING THE FUEL
SENDER” on page 8-106.
NG Replace the fuel pump assembly.
OK
2. Check the entire signaling sys-
tem’s wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
NG
Properly connect or replace the wire har-
ness.
OK
Replace the meter assembly.
The coolant temperature meter fails to operate.
1. Check the coolant temperature
sensor.
Refer to “CHECKING THE COOL-
ANT TEMPERATURE SENSOR”
on page 8-107.
NG Replace the coolant temperature sensor.
OK
2. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
NG
Properly connect or replace the wire har-
ness.
OK
Replace the ECU and/or meter as-
sembly.
To Next Page
