8-65
SEAT HEATER SYSTEM (for XP560D)
4. Check the seat heater.
Refer to “CHECKING THE SEAT
HEATER (for XP560D)” on page 8-
110.
NG Replace the seat assembly.
OK
Replace the meter assembly.
The temperature levels of the seat heater settings cannot be changed.
1. Check the menu switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
• The menu switch is faulty.
• Replace the handlebar switch (left).
OK
2. Check the select switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
• The select switch is faulty.
• Replace the handlebar switch (left).
OK
3. Check the wire harness between
the handlebar switch (left) and the
meter assembly.
NG
Properly connect or replace the wiring har-
ness.
OK
Replace the meter assembly.
To Next Page
