8-95
ELECTRICAL COMPONENTS
Starter relay
Headlight relay (dimmer)
First step:
Second step:
Radiator fan motor relay
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
Result
Continuity
(between “3” and “4”)
1. Positive tester probe
2. Negative tester probe
3. Negative tester probe
Result
Continuity
(between “1” and “2”)
No continuity
(between “1” and “3”)
12
G/R Br
Y/W
Y
Y/B BrL/B
2
1
3
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
5. Negative tester probe
Result
Continuity
(between “3” and “5”)
No continuity
(between “3” and “4”)
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
Result
Continuity
(between “3” and “4”)
+
1
2
3
5
4
Y/W
Y
Y/B BrL/B
Br/B
L
R/WY/R
4
3
2
1
