Yamaha TMAX TECH MAX 2020 User Manual

8-100
ELECTRICAL COMPONENTS
Smart key system relay (lock)
First step:
Second step:
1. Positive tester probe
2. Negative tester probe
3. Negative tester probe
A. XP560E
B. XP560D
Result
Continuity
(between “1” and “2”)
No continuity
(between “1” and “3”)
Br
B
Br/RR/L R/G
1
2
3
A
Br
B
R/BR/L R/G
1
2
3
B
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
5. Negative tester probe
A. XP560E
B. XP560D
Result
No continuity
(between “3” and “4”)
Continuity
(between “3” and “5”)
Br
B
Br/RR/L R/G
3
4
2
1
5
A
Br
B
R/BR/L R/G
3
4
2
1
5
B
